TMV – Water Cooled

TMVTMV – Water Cooled

🏢 Commercial AC

A specialized VRF solution that uses water as the heat exchange medium instead of outdoor air.

Model: TMV-WM/C-X

Series: TMV OUTDOOR | WATER COOLED

Inverter

Key Features

  • High Efficiency and Energy Saving
  • Abundant Capacity
  • Small Footprint
  • Low Noise
  • 2-stage enthalpy-adding control technology
  • Efficient and Reliable Water-Cooled Heat Exchange System
  • Wide Operation Range 10-50C water
  • 380-415V
  • 5.4-18cmh(water)
  • Up-to 80 IDU
Available Variants
Inverter
Specifications
TMV-W252WM/C-X Unit Value
Frequency Type Full DC Inverter
Sound Pressure Level dB(A) 50
Max Pipe Length m 150
Net Weight / Gross Weight ( kg 162/
Running Current A 7.4
Rated Current A 19.3
Power Supply Wire Size AWG AWG #12 X 5
Capacity HP 8.0 HP
Power Supply Wire Size V/Ph/Hz 340-415v/3n~/60hz
Ref. Pipe Size inch DN32; 3/8"; 3/4"
Dimensions | ODU (WxDxH) mm 780x550x1,000
Power Input W 4,400
Breaker Size A 25A
Communication Wire Qty. AWG AWG #18 X 2
Inverter
Specifications
TMV-W280WM/C-X Unit Value
Frequency Type Full DC Inverter
Sound Pressure Level dB(A) 50
Max Pipe Length m 150
Net Weight / Gross Weight kg 164/
Running Current A 8.9
Rated Current A 19.8
Power Supply Wire Size AWG AWG #12 X 5
Capacity HP 10.0 HP
Power Supply Wire Size V/Ph/Hz 340-415v/3n~/60hz
Ref. Pipe Size inch DN32; 3/8"; 7/8"
Dimensions | ODU (WxDxH) mm 780x550x1,000
Power Input W 5,250
Breaker Size A 25A
Communication Wire Qty. AWG AWG #18 X 2
Inverter
Specifications
TMV-W335WM/C-X Unit Value
Frequency Type Full DC Inverter
Sound Pressure Level dB(A) 50
Max Pipe Length m 150
Net Weight / Gross Weight kg 164/
Running Current A 10.2
Rated Current A 20.2
Power Supply Wire Size AWG AWG #12 X 5
Capacity HP 12.0 HP
Power Supply Wire Size V/Ph/Hz 340-415v/3n~/60hz
Ref. Pipe Size inch DN32; 1/2"; 1"
Dimensions | ODU (WxDxH) mm 780x550x1,000
Power Input W 6,050
Breaker Size A 25A
Communication Wire Qty. AWG AWG #18 X 2
Inverter
Specifications
TMV-W400WM/C-X Unit Value
Frequency Type Full DC Inverter
Sound Pressure Level dB(A) 50
Max Pipe Length m 150
Net Weight / Gross Weight kg 180/
Running Current A 12.3
Rated Current A 23.1
Power Supply Wire Size AWG AWG #12 X 5
Capacity HP 14.0 HP
Power Supply Wire Size V/Ph/Hz 340-415v/3n~/60hz
Ref. Pipe Size inch DN32; 1/2"; 1"
Dimensions | ODU (WxDxH) mm 780x550x1,000
Power Input W 7,300
Breaker Size A 32A
Communication Wire Qty. AWG AWG #18 X 2
Inverter
Specifications
TMV-W450WM/C-X Unit Value
Frequency Type Full DC Inverter
Sound Pressure Level dB(A) 50
Max Pipe Length m 150
Net Weight / Gross Weight kg 180/
Running Current A 15.7
Rated Current A 25.6
Power Supply Wire Size AWG AWG #12 X 5
Capacity HP 16.0 HP
Power Supply Wire Size V/Ph/Hz 340-415v/3n~/60hz
Ref. Pipe Size inch DN32; 1/2"; 1"
Dimensions | ODU (WxDxH) mm 780x550x1,000
Power Input W 9,300
Breaker Size A 32A
Communication Wire Qty. AWG AWG #18 X 2
Inverter
Specifications
TMV-W504WM/C-X Unit Value
Frequency Type Full DC Inverter
Sound Pressure Level dB(A) 56
Max Pipe Length m 150
Net Weight / Gross Weight kg 182/
Running Current A 17.5
Rated Current A 28.6
Power Supply Wire Size AWG AWG #12 X 5
Capacity HP 18.0 HP
Power Supply Wire Size V/Ph/Hz 340-415v/3n~/60hz
Ref. Pipe Size inch DN32; 5/8"; 1-1/8"
Dimensions | ODU (WxDxH) mm 780x550x1,000
Power Input W 10,350
Breaker Size A 32A
Communication Wire Qty. AWG AWG #18 X 2
Inverter
Specifications
TMV-W560WM/C-X Unit Value
Frequency Type Full DC Inverter
Sound Pressure Level dB(A) 58
Max Pipe Length m 150
Net Weight / Gross Weight kg 182/
Running Current A 24.3
Rated Current A 34.9
Power Supply Wire Size AWG AWG #10 X 5
Capacity HP 20.0 HP
Power Supply Wire Size V/Ph/Hz 340-415v/3n~/60hz
Ref. Pipe Size inch DN32; 5/8"; 1-1/8"
Dimensions | ODU (WxDxH) mm 780x550x1,000
Power Input W 1,440
Breaker Size A 40A
Communication Wire Qty. AWG AWG #18 X 2
