JETCOOL
Floor StandingJETCOOL
🏠 Residential AC
A high-performance floor-standing unit, the JETCOOL series integrates advanced inverter technology and smart connectivity for rapid cooling in large residential and commercial spaces.
Key Features
- TOSOT + Smart Wifi App Control
- Advanced Powerful Cooling Performance
- Turbo Cooling System
- 3D Air Flow System
- Intelligent Auto Restart Function
- Self Diagnosis Function
Available Variants
Inverter
Specifications
| TVC38VRT | Unit | Value |
|---|---|---|
| Horse Power | HP | 4 |
| Cooling Capacity | Kj/h | 38,340 (8,640 - 41,760) |
| EER | kJ/w-h | 12 |
| Power Supply | Volt | 230 |
| Frequency | Ph/Hz | 1/60 |
| Cooling Power Input | W | 3,200 (860 - 4,500) |
| Current Input | A | 19.91 |
| Airflow Volume | m3/h | 2,000 / 1,850 / 1,700 / 1,500 |
| INDOOR | ||
| Sound Pressure Level | dB (A) | 52 / 50 / 48 / 45 |
| Actual Dimension (LxDxH) | mm | 595x411x1,882 |
| Package Dimension (LxWxH) | mm | 150x735x530 |
| Net Weight / Gross Weight | Kg | 54 / 76.5 |
| OUTDOOR | ||
| Sound Pressure Level | dB (A) | 60 |
| Piping Connection Gas | mm (inch) | 16 (5/8) |
| Piping Connection Liquid | mm (inch) | 9.52 (3/8) |
| Maximum Piping Length | m | 30 |
| Actual Dimension (LxDxH) | mm | 1,000x427x746 |
| Package Dimension (LxWxH) | mm | 1,077x480x785 |
| Net Weight / Gross Weight | kg | 70 / 75 |
| Refrigerant | R | R32 |
Inverter
Specifications
| TVC60VRT | Unit | Value |
|---|---|---|
| Horse Power | HP | 6 |
| Cooling Capacity | Kj/h | 58,140 (12,960 - 61,200) |
| EER | kJ/w-h | 10.8 |
| Power Supply | Volt | 230 |
| Frequency | Ph/Hz | 1/60 |
| Cooling Power Input | W | 5,380 (360 - 5,800) |
| Current Input | A | 22 |
| Airflow Volume | m3/h | 2,100 / 1,950 / 1,750 / 1,650 |
| INDOOR | ||
| Sound Pressure Level | dB (A) | 53 / 49 / 47 / 46 |
| Actual Dimension (LxDxH) | mm | 595x411x1,882 |
| Package Dimension (LxWxH) | mm | 735x530x2,150 |
| Net Weight / Gross Weight | Kg | 58 / 80.5 |
| OUTDOOR | ||
| Sound Pressure Level | dB (A) | 61 |
| Piping Connection Gas | mm (inch) | 16 (5/8) |
| Piping Connection Liquid | mm (inch) | 9.52 (3/8) |
| Maximum Piping Length | m | 50 |
| Actual Dimension (LxDxH) | mm | 1,028x530x822 |
| Package Dimension (LxWxH) | mm | 1,070x560x853 |
| Net Weight / Gross Weight | kg | 87 / 98 |
| Refrigerant | R | R32 |
